SPECIAL MACHINE ANTI COVID
PALLET CLEANER
PALLET CLEANER
A Perfect Solution For Cleaning, Disinfection And Sanitization Of Goods loaded on Pallets
MIT has designed a fully automatic modular cabin, which adapts to every process of sanitizing and cleaning the incoming pallets to the production cycle: forced air cleaning, UV sanitization.
Pallets containing various types of packaging (glass, plastic, cardboard, etc.), especially if stored outside, are subject to attack and nesting of insects, the accumulation of cobwebs, foliage and other pollutants. Before entering the production cycle, especially if used in food production processes, they must be sanitized to avoid the entry of pollutants into production environments.
PALLETCLEANER is designed with the aim to introduce the market with a new combined technology (forced air & UVC) for cleaning and disinfection of goods loaded on pallets (glass bottles, plastic containers, cardboard, etc.) which can be included in a production cycle.
PALLETCLEANER is a perfect solution for the sectors that handles many pallets during production and for pallets containing various types of packaging packaging (such as glass bottles, plastic containers, cardboard, etc.), particularly if stored outside are subject to attack and nesting of insects, the accumulation of cobwebs, foliage and other pollutants, before entering the production cycle. Especially if used in food production processes, they must be sanitized to avoid the entry of pollutants into production environments.
FORCED AIR
CLEANING
UV-C
DISINFECTION
SAFE AND RELIABLE PROCESS
The interlocked shutter closing system prevents contamination of the rooms: the doors will not be opened simultaneously and the door inside the production department is only open when the pallet is been cleaned. The technology of the treatment is safe and reliable.
FORCED AIR
CLEANING
UV-C
DISINFECTION
FUNCTIONING
VERSIONE*
FORCED AIR
CLEANING
UV
DISINFECTION
| Pallet Dimensions | 1200 mm x 1000 mm Max height 2100 mm |
||
| Capacity | 50 L | ||
| Maximum mass | 1000 kg for each module | ||
| Temperature | Based on environmental temperature 0-40°C | ||
| Forced Air | 5.6 kW Centrifugal Fan and adjustable flow rate up to 7200 m3/h | ||
| UV | 1.1Kw UV-C | ||
| Voltage | 400V (3F + N + PE) | ||
| Frequency | 50 Hz | ||
| Installed power | 14 kW | ||
| Treatment room | L.180 x P. 150 x H.255 cm, attrezzato con:
|
||
| Loading conveyor | L. 150 x P. 140 cm
|
||
| Unloading conveyor | L. 150 x P. 140 cm
|
||
| Productivity | 12 pallet/hour (minimum treatment 1 pallet every 5 minutes) | ||
| Industry 4.0 | Certificabile | ||
| Mark | CE | ||
| Language of Panel and Manual | English | ||
*other technologies available on request
BENEFITS OF PALLETCLEANER
2 IN 1 – PALLETCLEANER is a combinable technology oven which has been designed by MIT SRL for industrial use especially for all the treatments in the entrance of the material in the productive areas. It has 2 main functions: cleaning and disinfection.
CONSUMPTION – Respecting the GO GREENconcept, with MIT OVENS you can save up energy. The combination of the heating technology permits high energy efficiency and reduce process time and consumption.
MANAGEMENT AND CONNECTIVITY – The oven is programmable from the operator panel, easy to operate touch screen, can store maximum number of recipes. The front panel is designed with a visual signaling system that indicates the indications the progress or the status of the oven.
MAINTENANCE – PALLETCLEANER is simple and easy to maintain; ordinary cleaning can be carried out safely by a single operator. The cabin can be easily cleaned at every corner, the technical cabinet is accessible by opening the sheet plated on the front, the filter can be removed separately and washed, the electric board is remoted in the productive area, all the command are remoted in an unique command center.
OVEN BUILT WITH HIGH QUALITY MATERIALS AND
DESIGNED TO LAST FOR A LONG TIME
